Schrödinger's Compiler

Author: Ibrahim El Kaddouri

Repository: Still under construction :(

STILL IN PROGRESS

Abstract

Modern compilers apply optimization passes in a fixed, hand-crafted order which is brittle. A pass applied too early can permanently destroy structure that a later pass could have exploited, the classic phase ordering problem. This project proposes a neurosymbolic optimizer for QBE, a lightweight compiler backend, that sidesteps this problem entirely. The symbolic half uses equality saturation (via e-graphs) to explore all valid program rewrites simultaneously and non-destructively, the neural half uses a graph neural network (GNN) trained with reinforcement learning to guide which rewrites are worth pursuing. Because every transformation the neural component selects is applied by the symbolic engine, correctness is guaranteed by construction, the RL agent never needs to check whether its output is valid, only whether it is fast.

Background

QBE

QBE is a compiler backend written in roughly 14000 lines of C. It accepts an SSA-form intermediate representation (IR) and emits optimized x86-64 or ARM64 machine code.

QBE IR

function w $add(w %a, w %b) {
@start
    %c =w add %a, %b
    ret %c
}

Each function is a set of basic blocks in SSA form, every variable is defined exactly once and the structure forms a directed acyclic graph (DAG) of operations. This structure is precisely what equality saturation is designed to work with.

E-graphs and equality saturation

An e-graph is a data structure that compactly represents a potentially enormous set of equivalent programs at once. The key insight is that rewrites are additive. Instead of replacing x * 2 with x << 1, an e-graph records that these two expressions are equivalent, both remain available. This means the order in which you apply rules does not matter, because no information is ever destroyed.

Equality saturation is the process of repeatedly applying rewrite rules to an e-graph until no new equalities can be added (saturation). Once saturated, you extract the cheapest program according to a cost model (e.g., instruction count, estimated latency). The open-source library egg provides a fast Rust implementation of this process, with Python bindings available.

A small taste of what rewrite rules might look like in egg’s rule syntax:

These rules are sound, they preserve program semantics, so any combination of them applied in any order yields a correct program.

The phase ordering problem

Traditional compilers run passes in sequence. First, dead-code elimination, then constant folding, then register allocation and so on. The problem is that applying pass A might block pass B from firing. Equality saturation solves this by never committing to a single form. All equivalent programs coexist in the e-graph simultaneously and the best one is extracted at the end.

However, equality saturation has its own problem. The e-graph can grow exponentially if all rules are applied indiscriminately. This is where the neural component enters.

Neurosymbolic guidance

Rather than applying all rewrite rules eagerly (which causes blowup) or in a fixed order (which reintroduces the phase ordering problem), a GNN policy learns to score which rules are most promising given the current e-graph state. The RL training loop rewards the agent for producing programs that run faster than the baseline QBE output.

This idea has been validated in adjacent domains. Omelette (Singh & Hall, 2022) showed that an RL system learning rewrite rule orderings for equality saturation can improve solution quality by up to 100% over standard egg. X-RLflow (He et al., 2023) applied a GNN-based RL agent to tensor computation graph optimization, outperforming cost-based search by exploiting long-horizon reward structure. Aurora (Barbulescu et al., 2024) applied the same principle to SQL query rewriting. None of these targeted a general-purpose low-level IR like QBE.

References

1. M Willsey, C Nandi, YR Wang, O Flatt, Z Tatlock, P Panchekha egg: Fast and extensible equality saturation. Proceedings of the ACM on Programming Languages 5 (POPL), 1-29

2. Singh, Z. (2022). Deep reinforcement learning for equality saturation. MPhil Thesis, University of Cambridge.

3. He, G., Singh, Z., & Yoneki, E. (2023). MCTS-GEB: Monte Carlo Tree Search is a Good E-graph Builder. Proceedings of EuroMLSys 2023. DOI: 10.1145/3578356.3592577 arXiv:2303.04651

4. He, G., Parker, S., & Yoneki, E. (2023). X-RLflow: Graph Reinforcement Learning for Neural Network Subgraphs Transformation. arXiv:2304.14698

5. Barbulescu, G.-O., Wang, T., Singh, Z., & Yoneki, E. (2024). Learned Graph Rewriting with Equality Saturation: A New Paradigm in Relational Query Rewrite and Beyond arXiv:2407.12794.

6. Mankowitz, D. J., et al. (2023). Faster sorting algorithms discovered using deep reinforcement learning. Nature, 618, 257–263.

7. Jia, Z., et al. (2019). TASO: Optimizing deep learning computation with automatic generation of graph substitutions. Proceedings of SOSP 2019.

8. Zayed A., & Dubach, C. (2025). DialEgg: Dialect-agnostic MLIR optimizer using equality saturation with Egglog. Proceedings of CGO 2025.

9. Merckx, J., Besard, T., & De Sutter, B. (2026). Equality Saturation for Optimizing High-Level Julia IR. ACM Transactions on Architecture and Code Optimization, 23(1), Article 24. DOI: 10.1145/3795883
