Minimal Language, Maximal Suffering

Author: Ibrahim El Kaddouri

Repository:

Have you ever wondered what happens when you type x = 5 in Python, or when you write const add = (a, b) => a + b in JavaScript ?

This project implements miniPlait, a small functional language designed to make the core ideas of programming languages concrete. It based on a project course by Brown Univeristy by Professor Shiram. The functional language implements lexical scoping, closures, syntactic desugaring and typing. The implementation progresses from an eager interpreter to a statically typed variant and finally to a lazy evaluator extended with typed recursion.

Introduction

Implementing a language is about choosing semantics (what programs mean), not just syntax (what programs look like). miniPlait is intentionally small, but still expressive enough to require real design decisions:

• Lexical scoping vs. dynamic scoping
• Surface syntax vs. core syntax
• Runtime checks vs. compile-time checks
• Eager evaluation vs. lazy evaluation

The code is structured as ‘phases’ (each one builds on the previous one):

• code/1-interp/: eager interpreter + desugaring
• code/3-tcheck/: standalone static type checker
• code/4-tynterp/: combined typed interpreter
• code/5-lazy/: lazy typed interpreter + rec

Implementation

Abstract Syntax Representation

The language uses algebraic data types to represent abstract syntax trees. The core expression type Expr includes:

(define-type Expr
  (e-num [value : Number])
  (e-str [value : String])
  (e-bool [value : Boolean])
  (e-op [op : Operator]
        [left : Expr]
        [right : Expr])
  (e-if [​cond : Expr]
        [consq : Expr]
        [altern : Expr])
  (e-lam [param : Symbol]
         [body : Expr])
  (e-app [func : Expr]
         [arg : Expr])
  (e-var [name : Symbol]))

Values produced by evaluation are represented as:

(define-type Value
  (v-num [value : Number])
  (v-str [value : String])
  (v-bool [value : Boolean])
  (v-fun [param : Symbol]
         [body : Expr]
         [env : Env]))

Notably, function values (v-fun) capture their defining environment, implementing lexical scoping through closure creation.

Part I: Core Interpreter

The foundational interpreter implements eager, call-by-value evaluation with environment-based variable resolution.

Environment Model

The interpreter maintains an immutable hash table mapping variable names to values:

(define-type-alias Env (Hashof Symbol Value))

Immutable hash tables ensure that environment extensions create new bindings without mutating existing ones, supporting proper lexical scoping and variable shadowing.

Evaluation Semantics

The interp function implements a post-order traversal of the abstract syntax tree, evaluating children left-to-right before processing parent nodes. This evaluation order provides deterministic error reporting when multiple errors exist in a program.

Binary Operations: The language supports four binary operators:

• Arithmetic addition (+) on numbers
• String concatenation (++) on strings
• Numeric equality (num=) returning booleans
• String equality (str=) returning booleans

Type checking occurs at runtime, raising errors when operands have incorrect types.

Conditional Expressions: The if construct evaluates its condition first. If the condition evaluates to true, the consequent branch executes; if false, the alternative branch executes. The implementation short-circuits evaluation, ensuring only the selected branch is evaluated. This property becomes important when branches contain errors or non-terminating computations.

Function Application: When applying a function to an argument, the interpreter:

1. Evaluates the function expression to a v-fun value
2. Evaluates the argument expression to a value
3. Extends the function’s captured environment with a binding from the parameter to the argument value
4. Evaluates the function body in this extended environment

This mechanism implements proper lexical scoping and closure semantics.

Error Handling

The interpreter raises exceptions for several error conditions:

• Unbound variables
• Type mismatches in operations (e.g., adding a string to a number)
• Non-boolean conditions in if expressions
• Attempting to apply non-function values

Errors follow Racket’s convention: (error <symbol> <message string>).

Part II: Syntactic Desugaring

Desugaring translates extended syntax into core language constructs, enabling language extensibility without modifying the interpreter.

Extended Abstract Syntax

The extended syntax representation Expr+ includes three sugar constructs:

(define-type Expr+
  ...
  (sugar-and [left : Expr+]
             [right : Expr+])
  (sugar-or [left : Expr+]
            [right : Expr+])
  (sugar-let [var : Symbol]
             [value : Expr+]
             [body : Expr+]))

Desugaring Transformations

Logical Conjunction (and): The expression (and e1 e2) desugars to:

(if e1 e2 false)

This encoding preserves short-circuit evaluation: if e1 evaluates to false, e2 is never evaluated.

Logical Disjunction (or): The expression (or e1 e2) desugars to:

(if e1 true e2)

Similarly, if e1 evaluates to true, e2 is not evaluated.

Variable Binding (let): The expression (let (x e1) e2) desugars to:

((lam x e2) e1)

This transformation reveals that let is syntactic sugar for immediate function application. The variable x is bound to the value of e1 in the scope of e2. Importantly, x is not bound in e1, preventing recursive definitions.

Desugaring Pipeline

The desugar function recursively transforms Expr+ trees into Expr trees, replacing all sugar constructs with their core equivalents while preserving program semantics. This separation of concerns allows the interpreter to remain simple while the language surface syntax can be extended freely.

Part III: Static Type Checker

The type checker implements a static type system that verifies program correctness before execution, catching type errors at compile time rather than runtime.

Type Language

The type system includes:

(define-type Type
  (t-num)
  (t-bool)
  (t-str)
  (t-fun [arg-type : Type]
         [return-type : Type])
  (t-list [elem-type : Type]))

Function types (t-fun arg-type return-type) represent the type of single-argument functions. List types (t-list elem-type) enforce homogeneity: all elements must have the same type.

Type Environment

The type checker maintains a type environment mapping identifiers to types:

(define-type-alias TEnv (Hashof Symbol Type))

This parallels the value environment used in the interpreter but operates at the type level.

Type Checking Rules

The type-of function implements bidirectional type checking using a post-order traversal:

Literals: Numbers have type (t-num), strings have type (t-str) and booleans have type (t-bool).

Binary Operations:

• + and num= require both operands to have type (t-num)
• ++ and str= require both operands to have type (t-str)
• Type mismatches raise TypeError exceptions

Conditionals: The condition must have type (t-bool). Both branches must have the same type, which becomes the type of the entire if expression. This ensures type safety regardless of which branch executes.

Lambda Abstractions: Lambda expressions require type annotations on parameters:

(lam (x : Num) (+ x 1))

The type of this function is (t-fun (t-num) (t-num)). The type checker verifies the body in an environment extended with the parameter’s declared type.

Function Application: When type-checking (f e), the type checker verifies:

1. The function f has type (t-fun arg-type return-type)
2. The argument e has type arg-type
3. The application has type return-type

Variable Binding (let): The expression (let (x e1) e2) is type-checked by:

1. Computing the type t1 of e1
2. Type-checking e2 in an environment extended with x : t1
3. The type of the entire expression is the type of e2

List Operations

Lists introduce several type checking challenges:

Empty Lists: The empty list (empty : t) requires an explicit type annotation because it has no elements to infer the type from. The annotation specifies the type of elements that will eventually be added.

List Construction: The expression (link x xs) requires:

• xs has type (t-list t) for some type t
• x has type t
• The result has type (t-list t)

List Deconstruction:

• (first xs) requires xs has type (t-list t) and returns type t
• (rest xs) requires xs has type (t-list t) and returns type (t-list t)
• (is-empty xs) requires xs has type (t-list t) and returns type (t-bool)

These rules ensure type safety for list operations while maintaining homogeneity.

Part IV: Integrated Typed Interpreter

The typed interpreter combines desugaring, type checking and interpretation into a unified evaluation pipeline.

Evaluation Pipeline

Program execution follows four stages:

1. Parsing: S-expressions are parsed into Expr+ (extended abstract syntax)
2. Desugaring: Expr+ is transformed into Expr (core abstract syntax)
3. Type Checking: type-of verifies type correctness and returns the program’s type
4. Interpretation: If type checking succeeds, interp evaluates the program to produce a value

This pipeline ensures that only well-typed programs are executed, catching many errors before runtime.

Error Delegation

The introduction of static type checking eliminates several classes of runtime errors:

Errors Caught by Type Checker:

• Unbound variable references
• Type mismatches in binary operations
• Non-boolean if conditions
• Type mismatches in function applications
• List operation type violations

Errors Remaining at Runtime:

• Accessing elements of empty lists (first and rest on empty lists)

The type system cannot distinguish between empty and non-empty lists because they share the same type (t-list t). This represents a fundamental limitation: proving that a list is non-empty requires dependent types or refinement types, which are beyond the scope of this type system.

Semantic Changes

Type checking introduces several semantic restrictions:

1. List Homogeneity: All list elements must have the same type. Previously valid programs like:

   (link 0 (link "hello" (empty : Str)))


   are now rejected.

2. Conditional Branch Uniformity: Both branches of an if expression must have the same type:

   (if true "string" 5)


   is rejected because the branches have different types.

3. Type Annotation Requirements: Lambda abstractions and empty lists require explicit type annotations.

These restrictions trade expressiveness for type safety, a common tradeoff in statically typed languages.

Modified let Syntax

The integrated interpreter requires type annotations on let bindings:

(let (x 4 : Num) (+ x x))

Part V: Lazy Evaluation

The final phase implements lazy evaluation, fundamentally changing how and when expressions are evaluated.

Lazy Evaluation Semantics

Lazy evaluation (also called call-by-need) delays computation until values are actually needed. When a function is called, its argument is not evaluated immediately. Instead, the unevaluated argument (a “suspension” or “thunk”) is passed to the function. The argument is evaluated only when the function’s body actually uses it.

This evaluation strategy enables several programming patterns impossible with eager evaluation:

• Infinite data structures
• Improved modularity through separation of data generation from consumption
• Potential performance improvements by avoiding unnecessary computations

Suspension and Forcing

The implementation uses suspension to represent delayed computations:

(define-type Value
  ...
  (v-suspension [expr : Expr]
                [env : Env]))

A suspension packages an expression with its environment. When the value is needed, it is “forced”: the expression is evaluated in its environment to produce a concrete value.

Strictness Points: Certain language constructs force evaluation:

• Binary operators force both operands
• if forces its condition and the selected branch
• first forces the head element of a list
• rest forces evaluation to determine if the list is empty, but does not force remaining elements
• The top-level eval forces the final result for display

Forcing is shallow: evaluating a list to determine it is non-empty does not recursively force its elements.

Recursive Definitions with rec

Lazy evaluation naturally supports recursive definitions through the rec construct:

(rec (name expr : type) body)

The variable name is bound in both expr and body, enabling self-referential definitions. This is essential for defining recursive functions that work on infinite structures:

(rec (nats-from (lam (n : Num)
                     (link n (nats-from (+ 1 n))))
                : (Num -> (List Num)))
  (nats-from 0))

This defines an infinite list of natural numbers. With eager evaluation, this would loop forever. With lazy evaluation, only the elements actually accessed are computed.

Infinite Streams Example

Consider a function take that extracts the first n elements from a stream:

(rec (take (lam (n : Num)
            (lam (s : (List Num))
             (if (num= n 0)
                 (empty : Num)
                 (link (first s)
                       ((take (+ n -1)) (rest s))))))
           : (Num -> ((List Num) -> (List Num))))
  ((take 3) (nats-from 0)))

This evaluates to (link 0 (link 1 (link 2 (empty : Num)))). The key insight: although nats-from generates an infinite list, only the first three elements are computed because take only accesses three elements.

With eager evaluation, (nats-from 0) would attempt to construct the entire infinite list before passing it to take, causing non-termination. Lazy evaluation decouples data generation from consumption, evaluating only what is needed.

Performance Considerations

While lazy evaluation enables elegant programming patterns, it introduces certain disadvantages:

• Each suspension requires memory allocation
• Debugging becomes more difficult because evaluation order is implicit

In practice, lazy evaluation is most valuable when it enables computations that would be impossible or impractical with eager evaluation, such as working with infinite structures or avoiding unnecessary expensive computations.

References

1. Krishnamurthi, S. (2020). Programming Languages: Application and Interpretation (PLAI). Version 3.2.5. Brown University. Available at: https://www.plai.org/3/5/plai-v325.pdf

2. Krishnamurthi, S. (2020). CSCI 1730: Programming Languages. Brown University. Course materials available at: https://cs.brown.edu/courses/csci1730/2020/

Appendix A: Grammar Summary

miniPlait Grammar (Eager, Untyped):

<expr> ::= <num> | <string> | <var>
         | true | false
         | (+ <expr> <expr>)
         | (++ <expr> <expr>)
         | (num= <expr> <expr>)
         | (str= <expr> <expr>)
         | (if <expr> <expr> <expr>)
         | (lam <var> <expr>)
         | (<expr> <expr>)

With Syntactic Sugar:

<expr> ::= ... (as above)
         | (and <expr> <expr>)
         | (or <expr> <expr>)
         | (let (<var> <expr>) <expr>)

Typed miniPlait Grammar:

<expr> ::= ... (as above)
         | (lam (<var> : <type>) <expr>)
         | (let (<var> <expr> : <type>) <expr>)
         | (first <expr>)
         | (rest <expr>)
         | (is-empty <expr>)
         | (empty : <type>)
         | (link <expr> <expr>)

<type> ::= Num | Str | Bool
         | (List <type>)
         | (<type> -> <type>)

Lazy miniPlait Additional Syntax:

<expr> ::= ... (as above)
         | (rec (<var> <expr> : <type>) <expr>)
